LED Track Lighting for Retail Stores

Retail track lighting puts adjustable LED heads on an electrified track, so the light follows the display. Built for European 3-circuit track, CCT-selectable and DALI-2 dimmable.

What Makes Track Lighting the Right Choice for Retail Spaces

A shop floor is never finished: heads slide, rotate and swap on the same live track, so a store can re-light a new display without re-wiring the ceiling. Four properties decide whether a track head actually performs in retail.

Energy Efficiency

Up to 160 lm/W means fewer heads for the same shelf illuminance and a lower connected load per meter of track — the figure a European project’s energy calculation is actually judged on.

Modern Design

Matched white and black finishes run across both the track panel and track linear ranges, so spotlights, accent runs and shelf lighting share one visual language on the same ceiling.

Versatility & Flexibility

One track run carries the whole scheme: 60° and 90° beam options, selectable color temperature and wattage, and 350° head rotation, so a display can be re-aimed without changing the fixture.

Reliable & High Quality

Commercial-duty components from Tridonic, Philips, Lumileds and Epistar, with every batch measured in-house on a goniophotometer and an integrating sphere before it ships.

How to Specify Track Lighting for a Retail Store

Specifying retail track lighting comes down to seven decisions: the track circuit, the beam angle, the color temperature, the color rendering index, the wattage per head, the glare rating and the dimming protocol. Get those seven right and one track run serves a fashion floor, a jewelry counter and a car showroom equally well.

The table below is the short version of the specification sheet our European customers send back to us with a quantity against it.

Specification decision	What it controls in the store	What OLAMLED supplies
Track circuit	How many independently switched groups one run can carry — window display, wall wash and general light on the same rail.	Adapters for European 230 V three-circuit track, in 4-wire and 6-wire versions.
Beam angle	Whether light lands tightly on the product or spills onto the floor and the customer.	60° and 90° on track panel heads; 60°, 90° and DS20° on the TK02 and TH linear heads.
Color temperature (CCT)	Whether merchandise reads warm and inviting or crisp and technical.	2800K–6500K, switch-selectable on the fixture rather than fixed at the factory.
Color rendering (CRI)	How faithfully fabric, skin tone, paintwork and food color appear under the beam.	CRI >80Ra as standard, CRI >90Ra on request for fashion, jewelry and gallery work.
Wattage per head	Illuminance on the shelf, and the connected load per meter of track.	40W–70W adjustable on track panel heads; 30W–55W adjustable on linear heads.
Glare control (UGR)	Visual comfort for the staff who stand under the run all day, and for shoppers looking up.	UGR <19 on the TD series, using a recessed low-glare optic.
Dimming protocol	Whether the scheme can join the building control system or stays a simple on/off circuit.	On/Off, 1–10V, DALI and DALI-2 versions of the same head.

Two of these decisions cause most of the rework on site. If the ceiling specification is not yet settled, start with the difference between 1-phase and 3-phase track. If the choice is between spot heads and continuous runs, track linear lighting versus trunking rail linear lighting sets out where each one belongs. For a wider view of the shop floor, including downlights and shelf lighting, see our retail display lighting buying guide.

Lighting Design Targets for a European Retail Space

European retail lighting is specified against EN 12464-1, the standard for lighting of indoor work places. It sets a maintained illuminance (Ēm), a glare limit (UGR) and a uniformity value (U0) for each zone of a shop, and those three numbers are what a consultant checks before a fixture is approved. Track heads have to be selected to hit them, not just to look right on the ceiling.

Retail zone	Maintained illuminance Ēm	Glare limit UGR	Uniformity U0	Color rendering Ra	Typical OLAMLED head
Sales area	300 lx	≤ 22	0.40	≥ 80	TK01 track panel head, 60° or 90°
Till area	500 lx	≤ 19	0.60	≥ 80	TD01 low-glare head, UGR <19
Wrapping / packing table	500 lx	≤ 19	0.60	≥ 80	TD01 or TD02 low-glare head
Display and feature accent	Set as a ratio to the sales area, not an absolute level	≤ 19 where staff face the beam	—	≥ 90 for fashion, jewelry and food	TK01 / TD01 at 60°, CRI >90Ra option
Perimeter and shelving wash	Even vertical illuminance on the goods	≤ 22	—	≥ 80	TK02 / TD02 / TH linear head, 120 cm or 150 cm

Zone values follow EN 12464-1 for retail premises. Accent contrast ratios are design practice rather than a standard requirement — most retail schemes work at roughly three to five times the general level on a feature display, which is why the accent layer is where the adjustable beam and the higher CRI grade earn their cost.

The practical consequence for a track scheme is that one color temperature and one beam angle cannot serve the whole floor. A sales area at 300 lx and a till at 500 lx with a tighter glare limit are two different specifications, which is exactly why the heads on this page are switch-selectable for wattage and color temperature and offered in both a standard and a UGR <19 optic.

Explore Our LED Track Light Series

High luminous efficacy, flexible wattage and color temperature, modern design, universal compatibility, multiple dimming options, low glare, and adjustable angles.

TK01 & TD01 Series: High-Efficiency Track Panel Lights for a Comfortable Light Environment

TK01 series for basic store lighting with up to 160LM/W luminous efficacy and flexible power and color temperature options. Choose the TD01 series for low-glare UGR<19 lighting in high-end retail. Both feature universal adapters for European 3-circuit tracks and support DALI and 1-10V dimming.

Models: OL-TK01 (40W-70W, adjustable power), OL-TD01 (40W-70W, adjustable power)
Luminous Efficacy: TK01 up to 160LM/W, TD01 up to 130LM/W Glare Control: TD01 series UGR<19
Beam Angle: 60°/90°
Color Temperature Options: 2800K - 6500K (CCT Selectable Switch)
Dimming Methods: On/Off, DALI, 1-10V
Application Scenarios: Shopping malls, brand stores, showrooms

TK02, TD02 & TH Series: Elegant Linear Lighting to Outline Commercial Spaces

Choose the TK02, TD02, and TH LED linear track lights for accent lighting with modern 120cm or 150cm lengths, multiple beam angles, selectable power and color temperature, dimming options, and high compatibility for atmosphere creation.

Models: TK02, TD02 series, TH series ((30W-55W, adjustable power)
Luminous Efficacy: Up to 160LM/W (TK02 and TH series)
Beam Angle: 60°/90°/DS20° (TK02 and TH series)
Length Options: 120cm / 150cm (for all series)
Color Temperature Options: 2800K - 6500K (CCT Selectable Switch)
Dimming Methods: On/Off, DALI-2, 1-10V (TK02,TD02 series)
Track Adapter: 4-wire/6-wire 3-circuit
Application Scenarios: Clothing store shelves, supermarket aisles, art galleries, office spaces

Specification Options: CCT, Wattage, Dimming, Glare Control and Track Compatibility

CCT Selectable

One head, several color temperatures. The switch on the fixture covers 2800K–6500K, so a warm 3000K fashion floor and a neutral 4000K supermarket aisle can be served from the same stock item. CRI is >80Ra as standard and >90Ra on request, specified per project.

Wattage Selectable

Power is adjustable on the fixture: 40W–70W on the track panel heads and 30W–55W on the linear heads. That lets one head hit the illuminance a display needs while keeping the connected load of the whole run inside the circuit budget. Other wattages can be set for your project.

Smart Dimming Options

The same head is built in On/Off, 1–10V, DALI and DALI-2 versions, so the fixture drops into a building control or store management system instead of forcing a separate control layer.

Low Glare Design (UGR<19)

The TD series uses a recessed low-glare optic rated UGR <19. That matters most at the till and anywhere staff face the beam all day, which is also where EN 12464-1 sets the tighter glare limit.

Universal Track Compatibility

Adapters are made for the European 230 V three-circuit track standard in 4-wire and 6-wire versions, so heads can be swapped into an existing rail without touching the ceiling.

Personalized Choice

350° flexible rotation. Each series has its own optic, housing depth and adapter option, so a project can mix panel heads and linear heads on a single track run and still keep one look.

Will These Heads Fit the Track Already on the Ceiling?

In most European retail refits, yes. The adapters are built for the 230 V three-circuit track standard used across Europe, in both 4-wire and 6-wire versions, so a store can change the heads and keep the existing rail, the existing feed positions and the existing ceiling. That is usually the difference between a weekend refit and a re-wire.

Three circuits, one rail

A three-circuit run carries three independently switchable groups from a single feed — typically window display, perimeter wall wash and general sales-floor light — so the shop can dim or switch zones without extra cabling.

The same head, four control versions

On/Off, 1–10V, DALI and DALI-2 variants share the housing and the optic. One product family covers a basic shop fit and a DALI-controlled flagship, which keeps a distributor’s stock list short.

Mixed heads on one run

Track panel heads and 120 cm / 150 cm linear heads sit on the same rail, so accent light on the display and even wash along the shelving come from one system and one finish.

Documentation for the destination market

Photometric files and test reports are issued per model, per order. If you are checking what a fixture has to satisfy before it enters the EU, our note on LED lighting regulations in the EU covers the current picture.

LED Track Lights in Retail Spaces: TK01, TD01, TK02, TD02 and TH Series on Video

LED Track Panel Light TK01 Series

LED Track Linear Light TK02 Series

LED Track Panel Light TD01 Series

LED Track Linear Light TD02 Series

LED Track Linear Lighting TH series

Retail and Commercial Spaces These Track Lights Are Built For

We work closely with local brand owners, engineers, and construction companies to provide comprehensive store track light solutions, from lighting design consultation to product supply. We understand your professional needs and are committed to delivering lighting products that meet architectural standards and design aesthetics.

Who We Supply in Europe

OLAMLED sells through the trade, not to the shop floor. Three buyer types account for most of our European track lighting volume, and each of them needs a different thing from the same product family.

Lighting distributors and electrical wholesalers

Own-brand track ranges with your packaging, your manual and your model codes. Low MOQ from 1 pc on standard products lets a catalog be tested before it is committed to.

Shopfitting and electrical contractors

Project quantities against a fixed specification, with the same color temperature, CRI and finish held across every phase of a multi-site rollout.

OEM / ODM brands and specifiers

Custom optic, housing, adapter, CCT and CRI, with tooling developed for you and the design kept confidential under NDA.

Send us the track type, the beam angle, the target illuminance and the quantity, and we quote against that specification rather than against a catalog page.

Retail Track Lighting Questions We Are Asked Most

What is the best lighting for a retail store?

A retail scheme normally uses two layers: a general layer that lifts the whole sales floor to a comfortable level, and an accent layer of track-mounted spotlights aimed at displays, mannequins and end caps. Track lighting is the accent layer, and it is chosen because the aiming can change as often as the merchandising does.

What are the three types of track lighting?

In Europe the practical split is single-circuit track, three-circuit (three-phase) track and low-voltage magnetic track. Single-circuit switches every head together, three-circuit gives three independently switchable groups on one rail, and magnetic systems suit slim recessed ceilings. North American listings instead use the H, J and L designations, which are not interchangeable with European track.

How many track lights can I put on one circuit?

Divide the current rating of the track and its supply by the input current of each head, then leave headroom for inrush. Because the heads on this page are wattage-adjustable, the same run can carry more heads at a lower setting. The 1-phase versus 3-phase explainer works through how the circuits are divided.

How much does commercial track lighting cost?

Price per head is driven by the optic, the wattage, the CRI grade, the dimming protocol and the order quantity — a plain on/off 40W head and a DALI-2 head with CRI >90Ra optics are not in the same band. As a factory we quote per specification, so tell us the configuration and the volume rather than asking for a list price.

What are the downsides of track lighting?

The hardware is visible, so the rail and the heads become part of the interior and have to be chosen for looks as well as output. A badly chosen optic also throws glare into shoppers’ eyes, which is why the low-glare UGR <19 option exists. And feed positions must be planned before the ceiling closes, because moving a feed later is a builder’s job, not an electrician’s.

Has track lighting been replaced by anything newer?

No. Magnetic low-voltage systems have taken some high-end interior work, but three-circuit track remains the standard for retail accent lighting in Europe because it is repairable, re-aimable and stocked by every wholesaler. It is the safest specification when a chain has to relight fifty stores over three years.
