Parking Lot Lighting Solution

Illuminate your spaces with high‑efficiency, durable and intelligent LED systems designed for car parks and garages.

Common Parking Lighting Challenges

Traditional parking lot lighting creates multiple problems for property managers and users

High Energy Costs

Traditional lighting consumes excessive energy, leading to high electricity bills and operational costs.

Frequent Maintenance

Constant bulb replacements and fixture repairs increase maintenance costs and downtime.

Safety Concerns

Poor illumination creates dark spots, increasing security risks and potential accidents.

Why Choose OLAMLED Parking Lot Lighting?

Transform your parking lots with our energy-efficient LED lighting systems. Advanced motion sensors, IP65/IP68 rated fixtures, and smart technology delivering superior illumination while reducing energy costs by up to 70%.

Sensor Control

Sensor Control to power intelligent lighting through motion detection. Lights turn on when vehicles or pedestrians arrive and turn off when they leave to maintain illumination and reduce energy waste.

Light Intensity Adjustment:

Light Intensity Adjustment actively manages garage lighting by sensing ambient light and adjusting lamp brightness accordingly. When daylight or nearby sources provide enough illumination, it dims the lights; in darker conditions like nighttime or overcast skies, it increases brightness to ensure consistent, safe visibility.

Time‑Segmented Control

Time‑Segmented Control to adjust lighting modes based on traffic flow data. Increase brightness and coverage during peak hours to improve safety. Lower lighting levels during off-peak hours to save energy and reduce emissions.

Safety and Comfor

Enhance safety and comfort in smart parking systems with adaptive lighting that adjusts to ambient conditions and user presence. Provide clear visibility and security while creating a welcoming environment for drivers and pedestrians.

IK10 Rating

IK10, the top mechanical impact protection rating, enables lamps to withstand strong external forces. This rating ensures durability against collisions and vandalism, making it vital for high-traffic and exposed environments.

IP65/IP68 Rating

IP65 and IP68 ratings protect lighting systems from dust, water, and harsh weather. These ratings ensure reliable operation in challenging outdoor conditions, from heavy rain to dust storms, delivering built-in durability and consistent performance.

Smart Sensor LED Tubular for Parking Garages – Energy-Efficient Lighting with Motion Detection

Using intelligent brightness-intermittent technology, smart sensor LED tubes are adopted as the lighting source for underground parking garages. The system enables high-brightness illumination when people or vehicles are present, and switches to low-brightness mode when the space is unoccupied, effectively balancing energy efficiency and safety.

Dimming Function

Item		Description	Remark
LED Tubular	Lumen	>5000lm
	luminous efficacy	>150lm/W
	color temperature	4000-4500K
	CRI	>80Ra
Sensor	Detecting Radius	≥4m(mount height 3m,moving speed 0.3m/s)
	Mounting Height	6m Max
	Daylight Sensor	5lux/15lux/30lux/50lux/100lux/150lux/Disable
	Detecting Angle	150°
	Detection Area	100%/75%/50%/25%
	Hold time	5s/30s/1min/3min/5min/10min/20min/30min

What series of OLAM products are suitable for Parking lot use?

LED tubular & Tri-proof lights designed by OLAMLED team are used extensively by customers on car parking lot & car wash.

IP65 Tri-proof light- U series
IP68 Tubular lights- K80 & K70 serie.

IP65 LED Tri-Proof Light U Series

Features of U series:

IP65,IK10
Aluminum base with PC Housing
Funtions: dimmable and non-dimmable driver optional
PC Housing: Frosted & Transpent

LED Tubular Light frosted & transparent

Features of K series:

IP68,IK10
304L or 316L End caps
PC or PMMA Housing
Funtions: dimmable and non-dimmable driver optional

Perfect for Various Applications

Our lighting solutions adapt to different parking environments and requirements

FAQ for Parking Lot Lighting Solutions

Here are some most popular FAQs during our 17 years experience as a LED lighting solution provider, and please feel free to contact us if you have more questions.

What smart controls should I consider?

Photocells for dusk/dawn, time scheduling, motion/occupancy trimming for late hours, and networked controls for remote monitoring and maintenance alerts—all to save energy and improve uptime.

How do I reduce glare and light trespass?

Choose full cut-off fixtures, appropriate optics and aiming, lower CCT if required, and respect property line maximums. Use shields where needed near residences.

How do I know if my lot is adequately lit?

Look for complaints, dark spots, poor camera footage, and conduct a photometric study to verify fc levels and uniformity against local code or site standards.

How often do parking lot lights need maintenance?

LEDs typically need minimal maintenance—periodic cleaning and inspections, with check-ups every 1–2 years; deeper service often at 5–10 years depending on environment and driver life.
